SPECYFIKACJA
Dual mono DAC
2x AKM AK4493 up to PCM 32bit/768kHz and DSD512
NETWORK PLAYER AND STREAMER
PCM and DSD256
DIGITAL INPUTS
1x RCA coaxial PCM asynchronous up to 24bit/192kHz
1x AES/EBU balanced PCM asynchronous up to 24bit/192kHz
2x TOS-Link PCM asynchronous up to 24bit/192kHz
1x USB-B asynchronous up to DSD512 and PCM up to 32bit/384kHz
1x USB-A port DSD256 and PCM up to 32bit/384kHz, formatted in FAT32/NTFS (32Gb max for pen drives)
ANALOGUE INPUTS (DS-1000 EVO LINE)
RCA unbalanced
XLR balanced
AUDIO OUTPUTS
DAC:
1 RCA 2Vrms, 1 XLR 2Vrms
Preamp:
1 RCA, 1 XLR, 1 headphone output with 6.3 mm jack
OUTPUT IMPEDANCE
RCA 50Ω
XLR 100Ω
FREQUENCY RESPONSE
20Hz-20kHz ±0.1dB
THD – TOTAL HARMONIC DISTORTION
0.001% max
SIGNAL TO NOISE RATIO
125dB
DYNAMIC RANGE
120dB
PREAMP STAGE VOLUME CONTROL
enabled/disabled
CONNECTIVITY
LAN/WLAN (Wi-Fi) 802.11a/b/g/n/ac Dual Band (10/433Mbps)
Bluetooth High-Definition 5.0 (44/16)
SUPPORTED AUDIO FORMATS (NETWORK)
Up to PCM 32bit/384kHz
DSD256 (DSF, DFF)
AIFF (.aif, .aiff, .aifc)
ALAC
WAV (.wav) packed/unpacked
FLAC
MP3
Apple Lossless
OGG
Monkey’s
IMPORTANT
UPnP server must support DSD streaming in
order to stream DSD files.
SUPPORTED MEDIA SERVERS
All UPnP
DLNA
Roon
POWER
Power supply 100-240V / 50-60Hz
Power consumption 30W
Fuse 2A T
DIMENSIONS
430mm W x 135mm H x 375mm D
WEIGHT
10kg net
15kg boxed
FINISHES
Brushed Aluminium in Black, Silver or Gold
REMOTE CONTROL
Multifunctional IR remote control
CONTROL APP
GN Control
available for iOS and Android
